Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of ACASA1000E3000P1AT is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | ACA - Precision |
Package: | Tape & Reel (TR) |
Part Status: | Active |
Circuit Type: | Isolated |
Resistance (Ohms): | 100, 300 |
Tolerance: | ±0.25% |
Number of Resistors: | 4 |
Resistor Matching Ratio: | ±0.05% |
Resistor-Ratio-Drift: | ±7.5ppm/°C |
Number of Pins: | 8 |
Power Per Element: | 125mW |
Temperature Coefficient: | ±25ppm/°C |
Operating Temperature: | -55°C ~ 155°C |
Applications: | Automotive AEC-Q200, Voltage Divider (TCR Matched) |
Mounting Type: | Surface Mount |
Package / Case: | 1206 (3216 Metric), Convex, Long Side Terminals |
Supplier Device Package: | - |
Size / Dimension: | 0.126" L x 0.059" W (3.20mm x 1.50mm) |
Height - Seated (Max): | 0.022" (0.55mm) |
RES ARRAY 4 RES MULT OHM 1206
