Type | Description |
---|---|
Series: | SMHC2511 |
Package: | Tape & Reel (TR) |
Part Status: | Active |
Type: | - |
Material - Core: | Metal |
Inductance: | 820 nH |
Tolerance: | ±20% |
Current Rating (Amps): | 13 A |
Current - Saturation (Isat): | 24A |
Shielding: | Shielded |
DC Resistance (DCR): | 8mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | - |
Operating Temperature: | -55°C ~ 125°C |
Inductance Frequency - Test: | 100 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard |
Supplier Device Package: | - |
Size / Dimension: | 0.280" L x 0.260" W (7.10mm x 6.60mm) |
Height - Seated (Max): | 0.118" (3.00mm) |
0.82UH, 20%, 6.7MOHM, 24AMP MAX.
