Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of ECS-HCMPI-0503Q-2R2M-T is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | ECS-HCMPI-0503Q |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Molded |
Material - Core: | - |
Inductance: | 2.2 µH |
Tolerance: | ±20% |
Current Rating (Amps): | 9.7 A |
Current - Saturation (Isat): | 9A |
Shielding: | Shielded |
DC Resistance (DCR): | 14.5mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | AEC-Q200 |
Operating Temperature: | -40°C ~ 125°C |
Inductance Frequency - Test: | 100 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard |
Supplier Device Package: | 5030 |
Size / Dimension: | 0.217" L x 0.209" W (5.50mm x 5.30mm) |
Height - Seated (Max): | 0.122" (3.10mm) |
FIXED IND 2.2UH 9.7A 14.5 MOHM
