Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of LPWI201210HR47T is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | LPWI |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Thin Film |
Material - Core: | Metal Composite |
Inductance: | 470 nH |
Tolerance: | ±20% |
Current Rating (Amps): | 4.3 A |
Current - Saturation (Isat): | 4.9A |
Shielding: | Shielded |
DC Resistance (DCR): | 28mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | - |
Operating Temperature: | -40°C ~ 125°C |
Inductance Frequency - Test: | 1 MHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | 0805 (2012 Metric) |
Supplier Device Package: | 0805 |
Size / Dimension: | 0.079" L x 0.047" W (2.00mm x 1.20mm) |
Height - Seated (Max): | 0.039" (1.00mm) |
