Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of FSP400-70MPE is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | MPE (500W) |
Package: | Box |
Part Status: | Active |
Type: | ATX |
Number of Outputs: | 6 |
Voltage - Input: | 90 ~ 264 VAC |
Voltage - Output 1: | 3.3V |
Voltage - Output 2: | 5V |
Voltage - Output 3: | 12V |
Voltage - Output 4: | 12V |
Current - Output (Max): | 32A, 30A, 18A, 18A, 200mA, 800mA |
Power (Watts): | 698W |
Applications: | ITE (Commercial), Medical |
Voltage - Isolation: | - |
Efficiency: | 78% |
Operating Temperature: | 0°C ~ 50°C (With Derating) |
Features: | PFC, Standby Output, Universal Input |
Mounting Type: | Chassis Mount |
Size / Dimension: | 5.91" L x 5.51" W x 3.39" H (150.0mm x 140.0mm x 86.0mm) |
Approval Agency: | CE, cURus, FCC, TUV, VCCI |
Standard Number: | 60601-1; 60950-1 |
