Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of S040W-056C1500-C02-UN-D2 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | SelectSYNC™ Intelligent (40W) |
Package: | Box |
Part Status: | Active |
Type: | Constant Current |
Topology: | AC DC Converter |
Number of Outputs: | 1 |
Voltage - Input (Min): | 108VAC |
Voltage - Input (Max): | 305VAC |
Voltage - Output: | 12 ~ 56V |
Current - Output (Max): | 0.3 ~ 1.5 A (700mA Default) |
Power (Watts): | 40 W |
Voltage - Isolation: | - |
Dimming: | Analog |
Features: | OCP, OTP, OVP, SCP |
Ratings: | IP20 |
Operating Temperature: | -30°C ~ 85°C |
Efficiency: | 84% |
Termination Style: | Terminal Block |
Size / Dimension: | 4.22" L x 2.36" W x 0.95" H (107.2mm x 59.9mm x 24.1mm) |
Approval Agency: | CE, cULus |
Standard Number: | - |
LED DVR CC AC/DC 12-56V 1.5A
