Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of VM.ECI6360DK1 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | ECI |
Package: | Bulk |
Part Status: | Active |
Type: | DC Motor |
Function: | Standard |
Motor Type: | Brushless (BLDC) |
Voltage - Rated: | 48VDC |
RPM: | 4000 RPM |
Torque - Rated (oz-in / mNm): | 124.6 / 880 |
Power - Rated: | - |
Encoder Type: | - |
Size / Dimension: | Round - 2.480" Dia (63.00mm) |
Diameter - Shaft: | 0.394" (10.00mm) |
Length - Shaft and Bearing: | 0.787" (20.00mm) |
Mounting Hole Spacing: | 1.929" (49.00mm) |
Termination Style: | Wire Leads |
Features: | - |
Gear Reduction Ratio: | - |
Torque - Max Momentary (oz-in / mNm): | - |
Operating Temperature: | 0°C ~ 40°C |
