Type | Description |
---|---|
Series: | AMPMODU Mod II |
Package: | Bulk |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.100" (2.54mm) |
Number of Positions: | 6 |
Number of Rows: | 1 |
Row Spacing - Mating: | - |
Number of Positions Loaded: | All |
Style: | Board to Board or Cable |
Shrouding: | Shrouded - 2 Wall |
Mounting Type: | Through Hole |
Termination: | Solder |
Fastening Type: | Latch Holder |
Contact Length - Mating: | - |
Contact Length - Post: | 0.126" (3.20mm) |
Overall Contact Length: | - |
Insulation Height: | 0.394" (10.00mm) |
Contact Shape: | Square |
Contact Finish - Mating: | Gold |
Contact Finish Thickness - Mating: | 3.90µin (0.099µm) |
Contact Finish - Post: | Tin |
Contact Material: | Phosphor Bronze |
Insulation Material: | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled |
Features: | - |
Operating Temperature: | -55°C ~ 105°C |
Ingress Protection: | - |
Material Flammability Rating: | UL94 V-0 |
Insulation Color: | Black |
Current Rating (Amps): | - |
Voltage Rating: | - |
