Current price of UW-09-628-Q(S) is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | Ultra |
Package: | Bulk |
Part Status: | Active |
Driver Circuitry: | Indicator, Internally Driven |
Input Type: | DC |
Voltage - Rated: | - |
Voltage Range: | 6 ~ 28V |
Frequency: | 2.1kHz |
Technology: | Piezo |
Operating Mode: | Warble, Slow |
Duration: | - |
Sound Pressure Level (SPL): | 93dB @ 6V, 61cm |
Current - Supply: | 20 ~ 50mA |
Port Location: | Top |
Operating Temperature: | -20°C ~ 65°C |
Approval Agency: | UL, UR |
Ratings: | - |
Ingress Protection: | IP68 - Dust Tight, Waterproof |
Mounting Type: | Panel Mount |
Termination: | Quick Connect Tab - 0.250" (6.35mm) |
Size / Dimension: | 1.410" Dia (35.81mm) |
Height - Seated (Max): | 1.380" (35.05mm) |
