Type | Description |
---|---|
Series: | SiSonic™ SPW |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | MEMS (Silicon) |
Output Type: | Analog |
Direction: | Omnidirectional |
Frequency Range: | 10 kHz ~ 10.0 kHz |
Sensitivity: | -44dB ±1dB @ 94dB SPL |
S/N Ratio: | 64.5dB |
Impedance: | 380 Ohms |
Voltage - Rated: | 1.8 V |
Voltage Range: | 1.6 V ~ 1.9 V |
Current - Supply: | 75 µA |
Port Location: | Bottom |
Ratings: | - |
Termination: | Solder Pads |
Size / Dimension: | 0.122" L x 0.098" W (3.10mm x 2.50mm) |
Height (Max): | 0.042" (1.06mm) |
Shape: | Rectangular |
