Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 2RS1-10-G is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | 2RS1 |
Package: | Tube |
Part Status: | Active |
Connector Type: | Receptacle |
Contact Type: | Female Socket |
Style: | Board to Board |
Number of Positions: | 10 |
Number of Positions Loaded: | All |
Pitch - Mating: | 0.079" (2.00mm) |
Number of Rows: | 1 |
Row Spacing - Mating: | - |
Mounting Type: | Through Hole |
Termination: | Solder |
Fastening Type: | Push-Pull |
Contact Finish - Mating: | Gold |
Contact Finish Thickness - Mating: | Flash |
Insulation Color: | Black |
Insulation Height: | 0.169" (4.30mm) |
Contact Length - Post: | 0.094" (2.40mm) |
Operating Temperature: | -40°C ~ 105°C |
Material Flammability Rating: | UL94 V-0 |
Contact Finish - Post: | Gold |
Mated Stacking Heights: | - |
Ingress Protection: | - |
Features: | - |
Current Rating (Amps): | 1A |
Voltage Rating: | 250VAC |
