224-5809-00-0602

Image is for reference,
please contact us to get the real picture

Part No :: 224-5809-00-0602

Manufacturer: 3M

Description: CONN SOCKET SIP ZIF 24POS GOLD

Catalog: Sockets for ICs, Transistors

Shipped from: HK warehouse

Expected Shipping Date: Jul 27 - Jul 31 2025

DataSheet: 224-5809-00-0602 PDF

Availability: 30 pieces

Unit Price: ~~$43.65000~~

Current price of 224-5809-00-0602 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

224-5809-00-0602 Specifications

Type	Description
Series:	Textool™
Package:	Bulk
Part Status:	Active
Type:	SIP, ZIF (ZIP)
Number of Positions or Pins (Grid):	24 (1 x 24)
Pitch - Mating:	0.100" (2.54mm)
Contact Finish - Mating:	Gold
Contact Finish Thickness - Mating:	-
Contact Material - Mating:	Beryllium Copper
Mounting Type:	Through Hole
Features:	-
Termination:	Solder
Pitch - Post:	0.100" (2.54mm)
Contact Finish - Post:	Gold
Contact Finish Thickness - Post:	30.0µin (0.76µm)
Contact Material - Post:	Beryllium Copper
Housing Material:	Polysulfone (PSU), Glass Filled
Operating Temperature:	-55°C ~ 125°C

Please confirm the specifications of the products when ordering.
