Type | Description |
---|---|
Series: | - |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
FET Type: | P-Channel |
Technology: | MOSFET (Metal Oxide) |
Drain to Source Voltage (Vdss): | 40 V |
Current - Continuous Drain (Id) @ 25°C: | 36A (Tc) |
Drive Voltage (Max Rds On, Min Rds On): | 4.5V, 10V |
Rds On (Max) @ Id, Vgs: | 17mOhm @ 18A, 10V |
Vgs(th) (Max) @ Id: | 2.5V @ 250µA |
Gate Charge (Qg) (Max) @ Vgs: | 55 nC @ 10 V |
Vgs (Max): | ±20V |
Input Capacitance (Ciss) (Max) @ Vds: | 2800 pF @ 10 V |
FET Feature: | - |
Power Dissipation (Max): | 1.2W (Ta), 56W (Tc) |
Operating Temperature: | 175°C (TJ) |
Mounting Type: | Surface Mount |
Supplier Device Package: | TO-252 (MP-3ZK) |
Package / Case: | TO-252-3, DPak (2 Leads + Tab), SC-63 |
