Current price of BSO201SPHXUMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | OptiMOS™ |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
FET Type: | P-Channel |
Technology: | MOSFET (Metal Oxide) |
Drain to Source Voltage (Vdss): | 20 V |
Current - Continuous Drain (Id) @ 25°C: | 12A (Ta) |
Drive Voltage (Max Rds On, Min Rds On): | 2.5V, 4.5V |
Rds On (Max) @ Id, Vgs: | 8mOhm @ 14.9A, 4.5V |
Vgs(th) (Max) @ Id: | 1.2V @ 250µA |
Gate Charge (Qg) (Max) @ Vgs: | 88 nC @ 4.5 V |
Vgs (Max): | ±12V |
Input Capacitance (Ciss) (Max) @ Vds: | 9600 pF @ 15 V |
FET Feature: | - |
Power Dissipation (Max): | 1.6W (Ta) |
Operating Temperature: | -55°C ~ 150°C (TJ) |
Mounting Type: | Surface Mount |
Supplier Device Package: | PG-DSO-8 |
Package / Case: | 8-SOIC (0.154", 3.90mm Width) |
