MSC015SMA070B

MSC015SMA070B

Image is for reference,
please contact us to get the real picture

Part No :

MSC015SMA070B

Manufacturer
Roving Networks / Microchip Technology
Description
SICFET N-CH 700V 131A TO247-3
Catalog
Transistors - FETs, MOSFETs - Single
Shipped from
HK warehouse
Expected Shipping Date
Jul 14 - Jul 18 2025
DataSheet
MSC015SMA070B PDF
Availability
508 pieces
Unit Price
$31.20000

Current price of MSC015SMA070B is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

MSC015SMA070B Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
FET Type:N-Channel
Technology:SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss):700 V
Current - Continuous Drain (Id) @ 25°C:131A (Tc)
Drive Voltage (Max Rds On, Min Rds On):20V
Rds On (Max) @ Id, Vgs:19mOhm @ 40A, 20V
Vgs(th) (Max) @ Id:2.4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:215 nC @ 20 V
Vgs (Max):+25V, -10V
Input Capacitance (Ciss) (Max) @ Vds:4500 pF @ 700 V
FET Feature:-
Power Dissipation (Max):400W (Tc)
Operating Temperature:-55°C ~ 175°C (TJ)
Mounting Type:Through Hole
Supplier Device Package:TO-247-3
Package / Case:TO-247-3
