IXYH24N170CV1

IXYH24N170CV1

Image is for reference,
please contact us to get the real picture

Part No :

IXYH24N170CV1

Manufacturer
Wickmann / Littelfuse
Description
IGBT 1.7KV 58A TO247
Catalog
Transistors - IGBTs - Single
Shipped from
HK warehouse
Expected Shipping Date
Aug 24 - Aug 28 2025
DataSheet
IXYH24N170CV1 PDF
Availability
139 pieces
Unit Price
$13.79000

Current price of IXYH24N170CV1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

IXYH24N170CV1 Specifications
Type Description
Series:XPT™
Package:Tube
Part Status:Active
IGBT Type:-
Voltage - Collector Emitter Breakdown (Max):1700 V
Current - Collector (Ic) (Max):58 A
Current - Collector Pulsed (Icm):140 A
Vce(on) (Max) @ Vge, Ic:4V @ 15V, 24A
Power - Max:500 W
Switching Energy:3.6mJ (on), 1.76mJ (off)
Input Type:Standard
Gate Charge:96 nC
Td (on/off) @ 25°C:16ns/155ns
Test Condition:850V, 24A, 5Ohm, 15V
Reverse Recovery Time (trr):170 ns
Operating Temperature:-55°C ~ 175°C (TJ)
Mounting Type:Through Hole
Package / Case:TO-247-3
Supplier Device Package:TO-247 (IXYH)
