Current price of OA938EC-UR-1WB is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | OA938EC |
Package: | Box |
Part Status: | Active |
Voltage - Rated: | 110/220VAC |
Size / Dimension: | Square - 92mm L x 92mm H |
Width: | 38.00mm |
Air Flow: | 60.0 CFM (1.68m³/min) |
Static Pressure: | 0.270 in H2O (67.2 Pa) |
Bearing Type: | Ball |
Fan Type: | Tubeaxial |
Features: | Dual Voltage, Electronic Commutation (EC) |
Noise: | 43.0dB(A) |
Power (Watts): | 2.20W |
RPM: | 3000 RPM |
Termination: | 2 Wire Leads |
Ingress Protection: | - |
Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
Approval Agency: | CE, cURus, TUV, UR |
Weight: | 0.420 lb (190.51 g) |
