Current price of F8025E24B-FHR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | F8025-H |
Package: | Bulk |
Part Status: | Active |
Voltage - Rated: | 24VDC |
Size / Dimension: | Square - 80mm L x 80mm H |
Width: | 25.00mm |
Air Flow: | 46.0 CFM (1.29m³/min) |
Static Pressure: | 0.210 in H2O (52.3 Pa) |
Bearing Type: | Ball |
Fan Type: | Tubeaxial |
Features: | Thermal Overload Protector (TOP) |
Noise: | 35.0dB(A) |
Power (Watts): | - |
RPM: | 3600 RPM |
Termination: | 2 Wire Leads |
Ingress Protection: | - |
Operating Temperature: | - |
Approval Agency: | CE, cUL, TUV, UL |
Weight: | 0.182 lb (82.55 g) |
