Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of PM3700-70-RC is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | PM3700 |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Filter Type: | - |
Number of Lines: | 2 |
Impedance @ Frequency: | - |
Inductance @ Frequency: | 10 mH @ 1 kHz |
Frequency Coupled to Inductance @ Frequency: | - |
Current Rating (Max): | 1.5A |
DC Resistance (DCR) (Max): | 150mOhm |
Voltage Rating - DC: | - |
Voltage Rating - AC: | - |
Operating Temperature: | -55°C ~ 125°C |
Ratings: | - |
Approval Agency: | - |
Features: | - |
Mounting Type: | Surface Mount |
Size / Dimension: | 0.850" L x 0.850" W (21.60mm x 21.60mm) |
Height (Max): | 0.450" (11.43mm) |
Package / Case: | Horizontal, 4 PC Pad |
