PH9455.105NL

PH9455.105NL

Image is for reference,
please contact us to get the real picture

Part No :

PH9455.105NL

Manufacturer
PulseLarsen Antenna
Description
CMC 1MH 22A 2LN 1.5 KOHM TH
Catalog
Common Mode Chokes
Shipped from
HK warehouse
Expected Shipping Date
Jul 15 - Jul 19 2025
DataSheet
PH9455.105NL PDF
Availability
589 pieces
Unit Price
$1.00000

Current price of PH9455.105NL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PH9455.105NL Specifications
Type Description
Series:-
Package:Tray
Part Status:Active
Filter Type:-
Number of Lines:2
Impedance @ Frequency:1.5 kOhms @ 15.94 MHz
Inductance @ Frequency:1 mH @ 15.94 MHz
Frequency Coupled to Inductance @ Frequency:-
Current Rating (Max):22A
DC Resistance (DCR) (Max):2.1mOhm
Voltage Rating - DC:-
Voltage Rating - AC:250V
Operating Temperature:-40°C ~ 125°C
Ratings:-
Approval Agency:-
Features:-
Mounting Type:Through Hole
Size / Dimension:1.181" L x 0.748" W (30.00mm x 19.00mm)
Height (Max):1.102" (28.00mm)
Package / Case:Vertical, 4 PC Pin
