ACMF-03-300-T

Image is for reference,
please contact us to get the real picture

Part No :: ACMF-03-300-T

Manufacturer: Abracon

Description: CMC 100MA 2LN 30 OHM SMD

Catalog: Common Mode Chokes

Shipped from: HK warehouse

Expected Shipping Date: Aug 16 - Aug 20 2025

DataSheet: ACMF-03-300-T PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of ACMF-03-300-T is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

ACMF-03-300-T Specifications

Type	Description
Series:	ACMF-03
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
Filter Type:	Signal Line
Number of Lines:	2
Impedance @ Frequency:	30 Ohms @ 100 MHz
Inductance @ Frequency:	-
Frequency Coupled to Inductance @ Frequency:	-
Current Rating (Max):	100mA
DC Resistance (DCR) (Max):	1.5Ohm (Typ)
Voltage Rating - DC:	-
Voltage Rating - AC:	-
Operating Temperature:	-55°C ~ 150°C
Ratings:	-
Approval Agency:	-
Features:	-
Mounting Type:	Surface Mount
Size / Dimension:	0.035" L x 0.027" W (0.88mm x 0.68mm)
Height (Max):	0.022" (0.55mm)
Package / Case:	0302 (0806 Metric), 4 Lead
