Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of ACF451832-221-TLD01 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | ACF |
Package: | Tape & Reel (TR) |
Part Status: | Not For New Designs |
Type: | Low Pass |
Filter Order: | 3rd |
Technology: | LC (T-Type) |
Number of Channels: | 1 |
Center / Cutoff Frequency: | - |
Attenuation Value: | 25dB @ 150MHz ~ 250MHz |
Resistance - Channel (Ohms): | 0.15 |
Current: | 300 mA |
Values: | - |
ESD Protection: | No |
Operating Temperature: | -25°C ~ 85°C |
Applications: | Data Lines for Mobile Devices |
Voltage - Rated: | 50V |
Mounting Type: | Surface Mount |
Package / Case: | 1812 (4532 Metric), 3 PC Pad |
Size / Dimension: | 0.177" L x 0.126" W (4.50mm x 3.20mm) |
Height: | 0.079" (2.00mm) |
