PF0553.473NLT

Image is for reference,
please contact us to get the real picture

Part No :: PF0553.473NLT

Manufacturer: PulseLarsen Antenna

Description: INDUCT ARRAY 2 COIL 47UH SMD

Catalog: Arrays, Signal Transformers

Shipped from: HK warehouse

Expected Shipping Date: Jul 09 - Jul 13 2025

DataSheet: PF0553.473NLT PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of PF0553.473NLT is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PF0553.473NLT Specifications

Type	Description
Series:	PF0553NL
Package:	Tape & Reel (TR)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	47 µH
Inductance - Connected In Series:	190 µH
Tolerance:	±20%
Current Rating - Parallel:	2.9 A
Current Rating - Series:	1.5 A
Current Saturation - Parallel:	5.3 A
Current Saturation - Series:	2.6 A
DC Resistance (DCR) - Parallel:	72mOhm Max
DC Resistance (DCR) - Series:	290mOhm Max
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.492" L x 0.492" W (12.50mm x 12.50mm)
Height:	0.315" (8.00mm)

Please confirm the specifications of the products when ordering.
