CIG22B1R0MAE

Image is for reference,
please contact us to get the real picture

Part No :: CIG22B1R0MAE

Manufacturer: Samsung Electro-Mechanics

Description: FIXED IND 1UH 1.3A 110 MOHM SMD

Catalog: Fixed Inductors

Shipped from: HK warehouse

Expected Shipping Date: Jul 27 - Jul 31 2025

DataSheet: CIG22B1R0MAE PDF

Availability: 0 pieces

Unit Price: ~~$0.05000~~

Current price of CIG22B1R0MAE is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

CIG22B1R0MAE Specifications

Type	Description
Series:	CIG22B_MAE
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Type:	Multilayer
Material - Core:	-
Inductance:	1 µH
Tolerance:	±20%
Current Rating (Amps):	1.3 A
Current - Saturation (Isat):	-
Shielding:	Shielded
DC Resistance (DCR):	110mOhm
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	1008 (2520 Metric)
Supplier Device Package:	1008 (2520 Metric)
Size / Dimension:	0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max):	0.031" (0.80mm)
