SDE0604A-560K

SDE0604A-560K

Image is for reference,
please contact us to get the real picture

Part No :

SDE0604A-560K

Manufacturer
J.W. Miller / Bourns
Description
FIXED IND 56UH 1.1A 420 MOHM SMD
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Aug 16 - Aug 20 2025
DataSheet
SDE0604A-560K PDF
Availability
332 pieces
Unit Price
$0.68000

Current price of SDE0604A-560K is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

SDE0604A-560K Specifications
Type Description
Series:SDE0604A
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Type:Wirewound
Material - Core:Ferrite
Inductance:56 µH
Tolerance:±10%
Current Rating (Amps):1.1 A
Current - Saturation (Isat):820mA
Shielding:Unshielded
DC Resistance (DCR):420mOhm Max
Q @ Freq:-
Frequency - Self Resonant:12MHz
Ratings:AEC-Q200
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:1 MHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.228" L x 0.205" W (5.80mm x 5.20mm)
Height - Seated (Max):0.189" (4.80mm)
