PA4306.223NLT

PA4306.223NLT

Image is for reference,
please contact us to get the real picture

Part No :

PA4306.223NLT

Manufacturer
PulseLarsen Antenna
Description
FIXED IND 22UH 1.5A 286 MOHM SMD
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Jul 04 - Jul 08 2025
DataSheet
PA4306.223NLT PDF
Availability
0 pieces
Unit Price
$0.94000

Current price of PA4306.223NLT is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PA4306.223NLT Specifications
Type Description
Series:PA4306.XXXNL
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Type:Wirewound
Material - Core:-
Inductance:22 µH
Tolerance:±20%
Current Rating (Amps):1.5 A
Current - Saturation (Isat):-
Shielding:Unshielded
DC Resistance (DCR):286mOhm Max
Q @ Freq:-
Frequency - Self Resonant:-
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.287" L x 0.287" W (7.30mm x 7.30mm)
Height - Seated (Max):0.122" (3.10mm)
