ELC-12E220L

Image is for reference,
please contact us to get the real picture

Part No :: ELC-12E220L

Manufacturer: Panasonic

Description: FIXED IND 22UH 2.8A 33 MOHM TH

Catalog: Fixed Inductors

Shipped from: HK warehouse

Expected Shipping Date: Aug 03 - Aug 07 2025

DataSheet: ELC-12E220L PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of ELC-12E220L is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

ELC-12E220L Specifications

Type	Description
Series:	12E
Package:	Bulk
Part Status:	Obsolete
Type:	Wirewound
Material - Core:	-
Inductance:	22 µH
Tolerance:	±10%
Current Rating (Amps):	2.8 A
Current - Saturation (Isat):	-
Shielding:	Shielded
DC Resistance (DCR):	33mOhm
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-
Inductance Frequency - Test:	10 kHz
Features:	-
Mounting Type:	Through Hole
Package / Case:	Radial, Vertical Cylinder
Supplier Device Package:	-
Size / Dimension:	0.531" Dia (13.50mm)
Height - Seated (Max):	0.768" (19.50mm)
