HCPL-3120-000E

HCPL-3120-000E

Image is for reference,
please contact us to get the real picture

Part No :

HCPL-3120-000E

Manufacturer
Broadcom
Description
OPTOISO 3.75KV 1CH GATE DVR 8DIP
Catalog
Isolators - Gate Drivers
Shipped from
HK warehouse
Expected Shipping Date
Jul 07 - Jul 11 2025
DataSheet
HCPL-3120-000E PDF
Availability
961 pieces
Unit Price
$3.29000

Current price of HCPL-3120-000E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

HCPL-3120-000E Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
Technology:Optical Coupling
Number of Channels:1
Voltage - Isolation:3750Vrms
Common Mode Transient Immunity (Min):25kV/µs
Propagation Delay tpLH / tpHL (Max):500ns, 500ns
Pulse Width Distortion (Max):300ns
Rise / Fall Time (Typ):100ns, 100ns
Current - Output High, Low:2A, 2A
Current - Peak Output:2.5A
Voltage - Forward (Vf) (Typ):1.5V
Current - DC Forward (If) (Max):25 mA
Voltage - Output Supply:15V ~ 30V
Operating Temperature:-40°C ~ 100°C
Mounting Type:Through Hole
Package / Case:8-DIP (0.300", 7.62mm)
Supplier Device Package:8-DIP
Approval Agency:CSA, UR
