HCPL-3180-500

Image is for reference,
please contact us to get the real picture

Part No :: HCPL-3180-500

Manufacturer: Broadcom

Description: OPTOISO 3.75KV GATE DRVR 8DIP GW

Catalog: Isolators - Gate Drivers

Shipped from: HK warehouse

Expected Shipping Date: Aug 15 - Aug 19 2025

DataSheet: HCPL-3180-500 PDF

Availability: 0 pieces

Unit Price: ~~$2.22322~~

Current price of HCPL-3180-500 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

HCPL-3180-500 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	10kV/µs
Propagation Delay tpLH / tpHL (Max):	200ns, 200ns
Pulse Width Distortion (Max):	65ns
Rise / Fall Time (Typ):	25ns, 25ns
Current - Output High, Low:	2A, 2A
Current - Peak Output:	2.5A
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	25 mA
Voltage - Output Supply:	10V ~ 20V
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	8-SMD, Gull Wing
Supplier Device Package:	8-DIP Gull Wing
Approval Agency:	CSA, UR
