Type | Description |
---|---|
Series: | - |
Package: | Tape & Reel (TR) |
Part Status: | Active |
Number of Channels: | 1 |
Voltage - Isolation: | 5000Vrms |
Current Transfer Ratio (Min): | 100% @ 5mA |
Current Transfer Ratio (Max): | 600% @ 5mA |
Turn On / Turn Off Time (Typ): | 3µs, 3µs |
Rise / Fall Time (Typ): | 2µs, 3µs |
Input Type: | DC |
Output Type: | Transistor |
Voltage - Output (Max): | 80V |
Current - Output / Channel: | 50mA |
Voltage - Forward (Vf) (Typ): | 1.25V |
Current - DC Forward (If) (Max): | 50 mA |
Vce Saturation (Max): | 300mV |
Operating Temperature: | -55°C ~ 110°C |
Mounting Type: | Surface Mount |
Package / Case: | 6-SOIC (0.295", 7.50mm Width), 4 Leads |
Supplier Device Package: | 6-SO, 4 Lead |
