Type | Description |
---|---|
Series: | MINAS A5 |
Package: | Bulk |
Part Status: | Active |
Type: | AC Motor |
Function: | Servomotor |
Motor Type: | - |
Voltage - Rated: | 200VAC |
RPM: | 3000 RPM |
Torque - Rated (oz-in / mNm): | 184.1 / 1300 |
Power - Rated: | 400W |
Encoder Type: | Absolute |
Size / Dimension: | Square - 2.362" x 2.362" (60.00mm x 60.00mm) |
Diameter - Shaft: | 0.551" (14.00mm) |
Length - Shaft and Bearing: | 1.181" (30.00mm) |
Mounting Hole Spacing: | 2.756" (70.00mm) |
Termination Style: | Connector |
Features: | Oil Seal |
Gear Reduction Ratio: | - |
Torque - Max Momentary (oz-in / mNm): | 538.1 / 3800 |
Operating Temperature: | 0°C ~ 40°C |
