Type | Description |
---|---|
Series: | XLamp® CXA1816 |
Package: | Tray |
Part Status: | Active |
Type: | Chip On Board (COB) |
Color: | White, Neutral |
CCT (K): | 4000K 4-Step MacAdam Ellipse |
Wavelength: | - |
Configuration: | Square |
Luminous Flux @ Current/Temperature: | 1433lm (1380lm ~ 1485lm) |
Current - Test: | 450mA |
Temperature - Test: | 85°C |
Voltage - Forward (Vf) (Typ): | 37V |
Lumens/Watt @ Current - Test: | 86 lm/W |
Current - Max: | 900mA |
CRI (Color Rendering Index): | 90 |
Viewing Angle: | 115° |
Features: | - |
Size / Dimension: | 17.85mm L x 17.85mm W |
Height: | 1.70mm |
Light Emitting Surface (LES): | 12.00mm Dia |
Lens Type: | Flat |
