Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of EC5BE15T is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | EC5BE (15W) |
Package: | Tube |
Part Status: | Active |
Type: | Isolated Module |
Number of Outputs: | 2 |
Voltage - Input (Min): | 18V |
Voltage - Input (Max): | 36V |
Voltage - Output 1: | 15V |
Voltage - Output 2: | -15V |
Voltage - Output 3: | - |
Voltage - Output 4: | - |
Current - Output (Max): | 500mA, 500mA |
Power (Watts): | 15 W |
Voltage - Isolation: | 500 V |
Applications: | ITE (Commercial) |
Features: | Remote On/Off, SCP |
Operating Temperature: | -25°C ~ 100°C (With Derating) |
Efficiency: | 83% |
Mounting Type: | Through Hole |
Package / Case: | 6-DIP Module |
Size / Dimension: | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) |
Supplier Device Package: | - |
Control Features: | Enable, Active High |
Approval Agency: | - |
Standard Number: | - |
