PTH05050WAZ

PTH05050WAZ

Image is for reference,
please contact us to get the real picture

Part No :

PTH05050WAZ

Manufacturer
Emerson Embedded Power (Artesyn Embedded Technologies)
Description
DC DC CONVERTER 0.8-3.6V 21W
Catalog
DC DC Converters
Shipped from
HK warehouse
Expected Shipping Date
Jul 26 - Jul 30 2025
DataSheet
PTH05050WAZ PDF
Availability
160 pieces
Unit Price
$12.15000

Current price of PTH05050WAZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PTH05050WAZ Specifications
Type Description
Series:PTH05050W (21W)
Package:Tray
Part Status:Active
Type:Non-Isolated PoL Module
Number of Outputs:1
Voltage - Input (Min):4.5V
Voltage - Input (Max):5.5V
Voltage - Output 1:0.8 ~ 3.6V
Voltage - Output 2:-
Voltage - Output 3:-
Voltage - Output 4:-
Current - Output (Max):6A
Power (Watts):21 W
Voltage - Isolation:-
Applications:ITE (Commercial)
Features:Remote On/Off, OCP, UVLO
Operating Temperature:-40°C ~ 85°C
Efficiency:95%
Mounting Type:Surface Mount
Package / Case:6-SMD Module
Size / Dimension:0.87" L x 0.50" W x 0.34" H (22.1mm x 12.7mm x 8.6mm)
Supplier Device Package:-
Control Features:-
Approval Agency:-
Standard Number:-
