AMSRL1-7809JZ

Image is for reference,
please contact us to get the real picture

Part No :: AMSRL1-7809JZ

Manufacturer: DComponents

Description: DC DC CONVERTER 9V 9W

Catalog: DC DC Converters

Shipped from: HK warehouse

Expected Shipping Date: Aug 10 - Aug 14 2025

DataSheet: AMSRL1-7809JZ PDF

Availability: 1198 pieces

Unit Price: ~~$3.56000~~

Current price of AMSRL1-7809JZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

AMSRL1-7809JZ Specifications

Type	Description
Series:	AMSRL1-78JZ (12W)
Package:	Tube
Part Status:	Active
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	13V
Voltage - Input (Max):	36V
Voltage - Output 1:	9V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	9 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	Adjustable Output, Remote On/Off
Operating Temperature:	-40°C ~ 55°C (With Derating)
Efficiency:	94%
Mounting Type:	Surface Mount
Package / Case:	10-SMD Module, 8 Leads
Size / Dimension:	0.60" L x 0.45" W x 0.32" H (15.2mm x 11.4mm x 8.5mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Please confirm the specifications of the products when ordering.
