ALE7PF24

ALE7PF24

Image is for reference,
please contact us to get the real picture

Part No :

ALE7PF24

Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPST 16A 24V
Catalog
Power Relays, Over 2 Amps
Shipped from
HK warehouse
Expected Shipping Date
Jul 24 - Jul 28 2025
DataSheet
ALE7PF24 PDF
Availability
0 pieces
Unit Price
$1.96200

Current price of ALE7PF24 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

ALE7PF24 Specifications
Type Description
Series:ALE
Package:Tray
Part Status:Not For New Designs
Mounting Type:Through Hole
Coil Voltage:24VDC
Contact Form:SPST-NO (1 Form A)
Contact Rating (Current):16 A
Switching Voltage:277VAC - Max
Coil Current:8.3 mA
Coil Type:Non Latching
Features:-
Termination Style:PC Pin
Seal Rating:-
Coil Insulation:Class F
Must Operate Voltage:18 VDC
Must Release Voltage:1.2 VDC
Operate Time:20 ms
Release Time:25 ms
Operating Temperature:-40°C ~ 85°C
Contact Material:Silver Tin Oxide (AgSnO)
Relay Type:General Purpose
