NC4D-JPL2-DC5V

NC4D-JPL2-DC5V

Image is for reference,
please contact us to get the real picture

Part No :

NC4D-JPL2-DC5V

Manufacturer
Panasonic
Description
RELAY GENERAL PURPOSE 4PDT 5A 5V
Catalog
Power Relays, Over 2 Amps
Shipped from
HK warehouse
Expected Shipping Date
Aug 01 - Aug 05 2025
DataSheet
NC4D-JPL2-DC5V PDF
Availability
0 pieces
Unit Price
$17.70000

Current price of NC4D-JPL2-DC5V is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

NC4D-JPL2-DC5V Specifications
Type Description
Series:NC
Package:Tube
Part Status:Active
Mounting Type:Through Hole
Coil Voltage:5VDC
Contact Form:4PDT (4 Form C)
Contact Rating (Current):5 A
Switching Voltage:250VAC - Max
Coil Current:320 mA
Coil Type:Latching, Dual Coil
Features:-
Termination Style:PC Pin
Seal Rating:-
Coil Insulation:-
Must Operate Voltage:4 VDC
Must Release Voltage:-
Operate Time:20 ms
Release Time:10 ms
Operating Temperature:-40°C ~ 55°C
Contact Material:Silver Nickel (AgNi)
Relay Type:General Purpose
