Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of ANT3216A063R2400A is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | - |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
RF Family/Standard: | 802.15.4, Bluetooth, WiFi |
Frequency Group: | UHF (2GHz ~ 3GHz) |
Frequency (Center/Band): | 2.4GHz |
Frequency Range: | 2.335GHz ~ 2.565GHz |
Antenna Type: | Chip |
Number of Bands: | 1 |
VSWR: | - |
Return Loss: | -10dB |
Gain: | 1.69dBi |
Power - Max: | 1 W |
Features: | - |
Termination: | Solder |
Ingress Protection: | - |
Mounting Type: | Surface Mount |
Height (Max): | 0.022" (0.55mm) |
Applications: | Bluetooth, WLAN, Zigbee™ |
