Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 42D36-02-1-AJN is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | 42 |
Package: | Bulk |
Part Status: | Active |
Number of Positions: | 2 ~ 10 |
Index Stops: | Adjustable |
Number of Decks: | 2 |
Number of Poles per Deck: | 1 |
Circuit per Deck: | SP10T |
Contact Timing: | Non-Shorting (BBM) |
Current Rating (Amps): | 1A (AC/DC) |
Voltage Rating - AC: | 115 V |
Voltage Rating - DC: | 28 V |
Actuator Type: | Flatted (6.35mm Dia) |
Actuator Length: | 11.10mm |
Angle of Throw: | 36° |
Contact Material: | Silver Alloy |
Contact Finish: | - |
Mounting Type: | Panel Mount |
Termination Style: | Solder Lug |
Features: | - |
Depth Behind Panel: | 34.82mm |
