Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of JF15RP3HE is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | JF |
Package: | Box |
Part Status: | Active |
Circuit: | SPST-NO |
Switch Function: | Off-Mom |
Contact Rating @ Voltage: | 0.05A @ 24VDC |
Actuator Type: | Square Button |
Mounting Type: | Through Hole |
Actuator Height off PCB, Vertical: | 6.78mm |
Actuator Length, Right Angle: | - |
Actuator Orientation: | Top Actuated |
Termination Style: | PC Pin |
Outline: | 22.80mm x 17.70mm |
Illumination: | Illuminated |
Illumination Type, Color: | LED, Yellow |
Illumination Voltage (Nominal): | 1.9 VDC |
Operating Force: | 200gf |
Ingress Protection: | - |
Features: | Process Sealed |
Operating Temperature: | -25°C ~ 70°C |
