PL20-16-130B

Image is for reference,
please contact us to get the real picture

Part No :: PL20-16-130B

Manufacturer: Tamura

Description: PWR XFMR LAMINATED 20VA TH

Catalog: Power Transformers

Shipped from: HK warehouse

Expected Shipping Date: Jul 26 - Jul 30 2025

DataSheet: PL20-16-130B PDF

Availability: 134 pieces

Unit Price: ~~$15.95000~~

Current price of PL20-16-130B is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PL20-16-130B Specifications

Type	Description
Series:	PL20-xx-130B
Package:	Bulk
Part Status:	Active
Type:	Laminated Core
Voltage - Primary:	115V, 230V
Voltage - Secondary (Full Load):	Parallel 8V, Series 16V
Current - Output (Max):	Parallel 2.5A, Series 1.25A
Primary Winding(s):	Dual
Secondary Winding(s):	Dual
Center Tap:	No
Power - Max:	20VA
Mounting Type:	Through Hole
Termination Style:	PC Pin
Size / Dimension:	57.20mm L x 47.60mm W
Height - Seated (Max):	41.28mm
Voltage - Isolation:	3500Vrms
Weight:	-

Please confirm the specifications of the products when ordering.
