PA3747.605NL

PA3747.605NL

Image is for reference,
please contact us to get the real picture

Part No :

PA3747.605NL

Manufacturer
PulseLarsen Antenna
Description
COMMON MODE CHOKE 1.55A 2LN TH
Catalog
Common Mode Chokes
Shipped from
HK warehouse
Expected Shipping Date
Jul 31 - Aug 04 2025
DataSheet
PA3747.605NL PDF
Availability
0 pieces
Unit Price
$5.22000

Current price of PA3747.605NL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PA3747.605NL Specifications
Type Description
Series:PA3747
Package:Tray
Part Status:Active
Filter Type:-
Number of Lines:2
Impedance @ Frequency:-
Inductance @ Frequency:-
Frequency Coupled to Inductance @ Frequency:-
Current Rating (Max):1.55A
DC Resistance (DCR) (Max):132mOhm
Voltage Rating - DC:-
Voltage Rating - AC:-
Operating Temperature:-40°C ~ 125°C
Ratings:-
Approval Agency:-
Features:-
Mounting Type:Through Hole
Size / Dimension:0.760" L x 0.717" W (19.30mm x 18.20mm)
Height (Max):0.902" (22.90mm)
Package / Case:Vertical, 4 PC Pin
